Laboratory Flake Ice Maker GYXH-85
In terms ofmanufacturing technology, we have core personnel with over 25years of experience in mechanical and electronic technology. Ourcircuit control systems are independently developed and holdmultiple patents, providing strong technical assurance for customerapplications
Product Message
- Product Description
- Product parameters
-
Ice production: 85kg/24h Floor-standing Standard version The floor-standing laboratory flake ice machine can efficiently produce amorphous, small, flake-like crushed ice. This type of ice can penetrate narrower gaps, offers fast cooling, and has a good ice bath effect. It is specifically designed for laboratories, particularly suitable for use in life sciences, medicine, agriculture, forestry, animal husbandry and fisheries, inspection and quarantine, and other laboratories. This ice machine is easy to operate, equipped with a voice prompt system, available in various models, visually appealing, beautiful and elegant, and equipped with lockable casters for convenient dragging and movement as needed!
Model Specifications Comparison:
Model GYXH-85 Other similar models Ice shape Irregular small granular snowflake crushed ice Irregular small granular Ice production (KG/24 hours) 85 80 Ice storage capacity (KG) 40 25 Color Off-white Off-white External dimensions (MM) 502*622*780 Unknown Reducer speed reduction method Right-angle hollow type (durable) Worm gear type Compressor Industry leading brand Not specified Microcomputer control system Yes Yes Anti-jam intelligent program setting Yes No Voice broadcast system Yes No LCD screen displays operation process Yes No Induction control method Infrared optical sensor (not affected by ambient temperature) Temperature sensing Note: Production is measured at an ambient temperature of 18 degrees and water temperature of 18 degrees
Product Usage
The ice produced by snowflake ice makers is relatively wet, with a water content generally between 15% and 25%, a temperature slightly below zero, good plasticity, and is easy to pick up and pile,
The irregular small granular snowflake crushed ice produced can penetrate into narrow gaps, has a fast cooling speed, and good ice bath effect. It is specially designed for laboratories, especially suitable for use in life
sciences, medicine, agriculture, forestry, animal husbandry, fishery, inspection and quarantine laboratories
Product Features
Easy to operate, one-button control from water inlet, ice making, ice crushing, extrusion, to dispensing snowflake ice, with automatic shutdown when ice is full
The entire operation process is completed by microcomputer self-control. Corresponding indicator lights will be displayed; the running light will be on, and the storage bin full indicator light will illuminate to stop operation
Adopts compressors from well-known industry-leading brands, ensuring stable and reliable operation
Adopts a row cavity partition structure, resulting in high ice making efficiency and large ice output
Fully computer program controlled, easy to operate
The ice storage bin uses fluorine-free polyurethane foam for good thermal insulation
Environmentally friendly refrigerant, R404A
Equipped with a 166*102mm touch control display screen, showing the ice machine operation process in real-time
Equipped with voice prompt system (important status voice prompt broadcast)
The entire machine system and casing can be separated for easy maintenance
Unique Safety Design
Automatically detects if the ice blade is running when starting up, preventing blade jamming;
Shuts down when the external water cut-off indicator light illuminates;
Automatically detects inlet water temperature and condensing temperature to adjust ice production;
Upon water cut-off shutdown and ice full shutdown, the refrigeration system is first turned off, and the ice blade continues to run for 60 seconds before shutting down automatically,
to avoid the ice blade being frozen when restarting the system immediately
Model Specifications
Product Model: GYXH-85
Capacity: 85 KG/24H
Ice Storage Capacity: 40 KG
Color Standard Version: Off-white
External Dimensions: 502*622*780 MM
