GYXH-75 Laboratory Ice Maker
In terms ofmanufacturing technology, we have core personnel with over 25years of experience in mechanical and electronic technology. Ourcircuit control systems are independently developed and holdmultiple patents, providing strong technical assurance for customerapplications
Product Message
- Product Description
-
Easy to operate, one click from water inlet, ice making, ice crushing, squeezing, and snowflake ice, with automatic shutdown when the ice is full.
Model Specifications:
Model GYXH-75 Other similar models/products Ice Shape Irregular small granular snowflake crushed ice Irregular small granular shape Ice Production (KG/24 hours) 75 70 Ice Storage Capacity (KG) 40 25 Color Off-white Off-white External Dimensions (MM) 502*622*780 Not specified Reducer deceleration method Right-angle hollow type (durable) Worm gear type Compressor Industry-leading brand Not identified Microcomputer control system Yes Yes Anti-jamming intelligent program setting Yes No Voice broadcast system Yes No LCD screen displays operating process Yes No Induction control method Infrared light sensing (not affected by ambient temperature) Temperature sensing Note: Production capacity is measured under conditions of 18 degrees room temperature and 18 degrees water temperature
Product Features
Easy to operate, one click from water inlet, ice making, ice crushing, squeezing, and snowflake ice, with automatic shutdown when the ice is full.
The entire operation process is controlled by a microcomputer, and the corresponding indicator light will be displayed. The running light will be on, and the refrigerator will stop running when the ice full indicator light is on.
Adopting well-known industry leading brand compressors, ensuring stable and reliable operation
Adopting a row cavity partition structure, with high ice making energy efficiency and large ice production capacity
Full computer program control, easy to operate
The ice storage bucket is made of fluorine-free polyurethane foam, with good insulation and insulation
Environmentally friendly refrigerant, R404A
Equipped with a 166 * 102mm touchable control display screen to display the operation process of the ice maker in real-time
Equipped with voice prompt system (important status voice prompt broadcasting)
The entire system and casing can be separated separately, making maintenance convenient
Unique safety design
Automatically detect whether the ice skate is running during startup to prevent it from getting stuck;
Stop the machine when the external water cut-off indicator light is on;
Automatically detect the temperature of the water inlet and adjust the ice production by condensing the temperature;
To shut down the machine when water is cut off or when the ice is full, first turn off the refrigeration system, continue running the ice skate for 60 seconds, and then turn it off on its own,
Avoid starting the system immediately. The ice skate has been frozen.
Product Usage
The ice shape of a snowflake ice maker is relatively damp, with a moisture content generally between 15% and 25%, and a temperature slightly below zero degrees Celsius. It has good plasticity and is easy to use and accumulate,
The ice produced is in the form of amorphous small particles, snowflake like broken ice that can penetrate narrow gaps, with fast cooling speed and good ice bath effect. It is specially designed for the laboratory and is particularly suitable for living
Used in laboratories such as life sciences, medicine, agriculture, forestry, animal husbandry, and fishing, and inspection and quarantine
Installation and use instructions
The ice maker should not be used outdoors, avoid places that are wet or easily exposed to water The ice machine should be placed in a place with no corrosive gas and good ventilation, and a distance of about 200mm should be left around to ensure that the machine has good ventilation and heat dissipation. When the ice maker is in place, the feet should be adjusted to make the machine stable, and it should be parked for about 10 hours for the first time before starting up. The drain pipe should be lower than the box to facilitate smooth drainage It is not allowed to pull the temporary line, and a fixed power socket should be installed A separate three-prong socket must be used and must be well grounded The power supply voltage should be used around 190~240V The ambient temperature should be around 5~35℃ When transporting, the machine should not be tilted more than 45°, and it is strictly forbidden to turn it upside down. Non-professional maintenance personnel are not allowed to open the machine for repair without authorization Do not modify the machine without authorization
Model specifications:
Product model: GYXH-75
Production capacity: 75KG/24H
Ice storage capacity: 40 KG
Material:Cold-reduced sheet
Ice form: amorphous small particles of snowflake like broken ice
Color Standard Edition: Grey White
External size: 502 *622 *780 MM
